Description

500 kg Self Load Stacker – 1600 mm

The Self Load Stacker 500 kg / 1600 mm is designed for businesses that need a compact and versatile solution for lifting and handling goods during warehouse, logistics and delivery operations.

Unlike a conventional pallet stacker used primarily inside a warehouse, a self-loading stacker is designed around the additional requirement of loading or unloading goods from suitable vehicles. Comparable self-loading stackers are specifically developed to load themselves into vans, pickups, lorries and trailers, helping reduce dependence on separate loading equipment.

With a 500 kg rated load capacity and 1600 mm lifting height, this configuration is suitable for light-duty palletized goods and other compatible loads.

500 kg Load Capacity

The stacker has a specified 500 kg load capacity, making it suitable for handling lighter loads in commercial, warehouse and delivery environments.

Typical applications can include:

• Light pallets
• Boxes and cartons
• Packaging materials
• Industrial components
• Retail goods
• Equipment
• Spare parts
• General warehouse materials

1600 mm Lifting Height

The 1600 mm maximum lifting height provides sufficient vertical lifting capability for a range of light-duty loading, unloading and storage applications.

A 1600 mm lift can be useful for positioning goods at suitable storage levels and for raising compatible loads during vehicle loading and unloading operations.

Self Loading Capability

The main advantage of a self load stacker is its ability to assist with vehicle loading operations.

Self-loading stackers are designed so that the equipment can be used as part of the loading process, potentially allowing the machine to be transported with a delivery vehicle and then used at the destination for unloading and handling.

This can be particularly useful for:

• Delivery companies
• Distribution businesses
• Service teams
• Mobile warehouse operations
• Small logistics companies
• Contractors
• Businesses making frequent deliveries

Applications

The 500 kg Self Load Stacker 1600 mm can be used for:

• Truck loading and unloading
• Van loading and unloading
• Pickup loading operations
• Trailer loading
• Delivery operations
• Warehouse material handling
• Light pallet handling
• Retail goods handling
• Workshop material handling
• Distribution operations
• Loading bay operations
• Industrial material movement
• Mobile delivery applications



The 500 kg Self Load Stacker with 1600 mm lifting height is positioned as a compact solution for businesses that need to combine light-load lifting with delivery and vehicle-loading operations.

It can be considered where businesses require:

• Compact material handling equipment
• Light-load lifting
• Vehicle loading support
• Warehouse handling
• Delivery-site handling
• Pallet lifting
• Loading and unloading assistance
